UBIQUITI NANOSTATION M5-EU


NanoStation M5 NSM5 5GHz 16dBi, 5GHz Hi Power 2×2 MIMO AirMax TDMA Station, featuring a panel antenna and dual-polarity performance, ideal for Point-to-MultiPoint (PtMP) applications requiring high-performance CPE.

Model No NSM5-EU
Frequency 5 GHz
Throughput 150 Mbps
Gain 16dBi
Ports (2) 10/100 Ethernet Port
Range 15 km
Operating Frequency (MHz) 5150 – 5350, 5470 – 5725, 5725 – 5875

NanoStation M5: 5GHz Hi Power 2×2 MIMO AirMax TDMA Station.

  • The original NanoStation set the bar for the world’s first low-cost and efficiently designed outdoor broadband CPE. The new NanoStation M and NanoStation Loco M take the same concept to the future with new redesigned sleek and elegant form-factors.
  • 150 Mpbs real outdoor throughput and up to 15km range. Featuring 2×2 MIMO technology, the new NanoStation links significantly faster and farther than ever before.
  • New antenna array designs featuring 16dBi dual-polarity gain at 5GHz.
  • Secondary ethernet port with software enabled POE output for seamless IP Video integration.
  • Remote hardware reset circuitry of NanoStation M allows for the device to be reset remotely from power supply location.
  • In addition, any NanoStation can easily become 802.3af 48V compliant through use of Instant 802.3af adapter.

Specification

  • Operation mode AP, Client, WDS
  • Frequency 5,4 – 5.825 GHz
  • DHCP yes
  • Transmission speed 300 Mbps
  • Standards 802.11a/n
  • Chipset Atheros
  • TX Power regulation yes
  • output power 27 dBm
  • Sensitivity -96 dBm
  • Modulation OFDM
  • Encryption WEP 64/128/152, WPA, WPA2, 802.1X
  • LAN port 2x RJ45 10/100 Mbps
  • Default IP 192.168.1.20
  • Default name ubnt
  • Default password ubnt
  • Power supply 15 V, 0,8 A
  • Operational temperature -30 – 80 °C
  • Dimension 294 x 80 x 30 mm
  • Interface LAN, WiFI
  • Supported OS AirOS V
  • Polarization H/V
  • Radiating angle – H 43°/41°
  • Radiating angle – V 15°
  • Processor MIPS 24KC, 400 MHz
  • RAM 32 MB
  • NAND 8 MB
