Tenda TEG1124P-24-250W

”

TENDA TEG1124P-24-250W DESCRIPTION

TEG1124P-24-250W    /    SWITCH    /    1000M&POE 24-PORT GIGABIT ETHERNET SWITCH WITH 24-PORT POE

TEG1124P-24-250W is a Tenda PoE switch that offers 24 10/100/1000 Mbps Base-TX RJ45 ports. Ports 1-24 comply with the IEEE 802.3af standard (maximum PoE power output: 15.4 W) and 802.3at standard (maximum PoE power output: 30 W). The switch offers a maximum PoE power output of 225 W and can supply power to and exchange data with APs, IP cameras, and IP phones through CAT5 cables. It also provides simple management modes such as CCTV, VLAN, and isolation to help reduce cabling costs of IP terminals like APs and IP cameras.

Born for Surveillance

24-Port Gigabit Desktop/Rackmount Switch With 24-Port PoE

6KV Lightning Protection PoE Switch is the only engineering switch

In real projects, APs and cameras are often installed outdoors or at an elevated location, which increases the chance of lightning strikes on cameras and PoE-powered switches. The result is that individual devices are damaged when the outcome is light, and even the whole local area network is damaged. Tenda TEG11 series switches have a professional lightning protection design – 6KV Lightning Protection for Ports and the power, and they have two levels of protection design respectively, which effectively suppress the lightning current from the network cable and power supply, equivalent to adding a security wall to the entire network monitoring system. The test standard is much higher than the national CCCrequest. In a thunderstorm, Tenda TEG11 series switches can also provide a stable and reliable service to the surveillance network and guarantee the normal transmission of the picture.

CCTV, Standard, VLAN and Isolation Operation Modes Offered

Standard: The switch functions as a common unmanaged switch and all the ports of the switch can communicate with each other.

CCTV: The port cache is optimized and PoE ports 1-8 have higher priorities over the other ports. All the ports of the switch can communicate with each other.

VLAN: Ports 1 to 22 are isolated from each other, but can communicate with ports 23 and 24 (uplink ports) respectively.

Isolation: Ports 1 to 12 and ports 13 to 24 belong to two different VLANs. This mode can be used to isolate the supervision networks and wireless networks to make them not interfere with each other.

225W PoE power supply simplified wiring

Ports 1-24 comply with the IEEE802.3af and IEEE802.3at power supply standards. The entire switch offers a maximum PoE power output of 225W, whereas each port offers a maximum PoE power output of 30 W. The ports can be used to supply power to and exchange data with APs and IP cameras.

Specification

Standard&Protocol

IEEE 802.3/IEEE 802.3u/IEEE 802.3ab/IEEE 802.3x/IEEE 802.3af/IEEE 802.3at

Indicator

24*Link/Act per device

24*PoE per device

1*Power per device

Interface

24 10/100/1000Base-T ports(Data/Power)

Lightning Protection

6KV

Store & Forward

Yes

exchange capacity

48 Gbps

Packet Forwarding Rate

35.6Mpps

RAM Data Buffer

4Mb

MAC Address Table

4K

PoE supply management

Port 1-24 support IEEE802.3at/af PoE standard

PoE through pin

1 2 4 5 /3 6 7 8 –

Input Power

AC: 100-240V?50/60Hz

Dimension

440*178*44mm( W x D x H )

Power Consumption

in full configuration: <250W

PoE Max Power Supply: 225W

Port Features

Standard: the switch functions as a common unmanaged switch and all the ports of the switch can communicate with each other.

CCTV: the port cache is optimized and PoE ports 1-8 have higher priorities

over the other ports. All the ports of the switch can communicate with each other.

VLAN: ports 1 to 22 are isolated from each other, but can communicate with ports 23 and 24(uplink ports) respectively.

Isolation: ports 1 to 12 and Ports 13 to 24 belong to two different VLANs.This mode can be used to isolate the supervision networks and wireless networks to make them not interfere with each other.

Environment

Operating Temperature: 0?~40? (32?~104?)

Storage Temperature: -40?~70? (-40?~158?)

Operating Humidity: 10%~90% non-condensing

Storage Humidity: 5%~90% non-condensing”
