Tenda TEG5328F


TEG5328F is a Tenda Layer-3 managed switch. To meet the demand of high-performance access, the switch provides 24 10/100/1000 Mbps Base-T Ethernet ports and 4 separate 1000 Mbps Base-X SFP ports.

 35,000

Compare

TENDA TEG5328F DESCRIPTION

TEG5328F    /    SWITCH    /    L3 MANAGED SWITCH

TEG5328F is a Tenda Layer-3 managed switch. To meet the demand of high-performance access, the switch provides 24 10/100/1000 Mbps Base-T Ethernet ports and 4 separate 1000 Mbps Base-X SFP ports. With an innovative hardware structure and software platform, it features a powerful processing capacity and complete security protection mechanism, making management and maintenance easy and simple, fully meeting the demands of high-density user access and high-performance aggregation, ideal for the aggregation layer or core layer of such medium to large networks as enterprises and campuses.

Specification

Model
TEG5328F
Network standard
IEEE802.3? IEEE802.3u? IEEE802.3ab? IEEE802.3ad? IEEE802.3z? IEEE802.3x?IEEE802.1p? IEEE802.1q? IEEE802.1w? IEEE802.1d? IEEE802.1s
LED indicator
One Link/Act LED indicator for each port
One Power LED indicator for each device
One SYS LED indicator for each device

Interface

24 x 10/100/1000 Base-T Ethernet ports
4 x 1000 Base-X SFP ports
1 x Console port
Fan Quantity
None
Level of protection
Lightning protection for ports: ?6kV (common mode)
Lightning protection for power: ?6kV (common mode), ?4kV (differential mode)
ESD:
Air discharge: ±8kV
Contact discharge: ±6kV
Forwarding Mode
Store-and-forward
Switching Capacity
56Gbps
Packet Forwarding Rate
41.7Mpps
Buffer
12Mb

MAC Address Learning

16K
Jumbo Frame
10K
PoE power supply
N/A
PoE budget
N/A
Input Voltage
100-240V AC 50/60Hz
Power Consumption
Full load: ?24W
Empty load: ?10W

Dimension

440 mm x 178.8 mm x 44 mm(L*W*H)
Mounting options
Desktop mounting
Rack mounting (19? 1U)
Wall mounting
Energy Efficient

Support

Environment
Operating temperature: 0°C – 45?
Storage temperature: -40°C – 70°C
Operating humidity: (10% – 90%)RH, non-condensing
Storage humidity: (5% – 90%)RH, non-condensing

Certification

CCC?FCC?CE?RoHS
L3 Features
Supports VLAN-based routing
Supports IPv4 static routing
Supports static ARP
Security features
ARP receiving limit
Unknown MAC address discard
DoS attack defense
802.1x security authentication

Radius authentication

VLAN
IEEE 802.1Q VLAN
VLAN Layer-3 interfaces
Supports three port modes: Access, Trunk and Hybrid
DHCP
DHCP Relay
DHCP Snooping
Supports Option 82 policy configuration
Port Aggregation
Static aggregation
LACP dynamic aggregation

Spanning tree

IEEE 802.1d STP (Spanning Tree Protocol)
IEEE 802.1w RSTP (Rapid Spanning Tree Protocol)
IEEE 802.1s MSTP (Multiple Spanning Tree Protocol)
Supports edge port
Supports BPDU statistics
Multicast
IGMP Snooping V1/V2/V3
Supports port fast leave

Port Mirroring

Supports N: 1 port mirroring
QoS
SP (Strict Priority)
SWRR (Simple Weighted Round Robin)
WRR (Weighted Round Robin)
Supports 802.1p port trust mode
Supports DSCP port trust mode
Supports a maximum of 8 queue service quality mapping

ACL

Supports MAC ACL and IP ACLLoading and upgrade
Supports FTP/TFTP/HTTP upgrade
Supports configuration import and export
Management and maintenance
Supports Telnet, Console
Supports SNMP V1/V2/V3
Supports WEB management and maintenance
Supports Ping/Tracert/Connection Detection
CPU Monitoring and memory monitoring”
